Klavins Lab Turbidostat Wiki | OperatingManual / SetupAssembleClosedSystem

August 16, 2014, at 04:05 PM by chris -

Changed line 70 from:

Wrap all culture vessel export ports in aluminum foil

to:

Wrap all culture vessel effluent tube openings in aluminum foil

Changed line 72 from:

Double check that all open ends of the tubing system, export ports, and air filters are properly wrapped in aluminum foil

to:

Double check that all open ends of the tubing system, effluent ports, and air filters are properly wrapped in aluminum foil

Added line 80:

As soon as the autoclave finishes remove the foil from only the air filters. This will allow them to dry. Only dry filters will pass air.

August 16, 2014, at 04:02 PM by chris -

Changed lines 65-68 from:

Connect a Luer lock end of a 2' tubing section of the octopus tubing system to an inport port on the culture vessel
Connect an air filter to the other inport port on the culture vessel
Repeat for the 7 remaining culture vessels
- After this step, the culture vessels should only have their export ports open to the environment

to:

For each culture tube
1. Connect one of the Female Luer ends from the culture tube to one of the male ends on the tubing manifold.
2. Connect an air filter to the other Female Luer port on the culture vessel
- After this step, the culture vessels should only have their effluent ports open

August 16, 2014, at 03:57 PM by chris -

Changed lines 52-54 from:

Wash with soap and water
- Make sure to clean all biofilms off of culture tube walls
Rinse culture tube with ethanol

to:

Wash with soap and water using a tube brush

Changed lines 54-55 from:

Clean magnetic stir bar
1. Rinse with ethanol

to:

Clean magnetic stir bar with soap and water

Changed line 56 from:

Place stir bar into culture tube with a little bit of DI water

to:

Place stir bar into culture tube with a little bit of DI water (whatever is left from rinsing is okay)

Changed lines 58-61 from:

Plug

Rinse out input ports with ethanol
Rinse out export port with ethanol
Securely place plug into culture tube

to:

Stopper

Rinse out input ports with ethanol from a squeeze bottle
Rinse out export port with ethanol from a squeeze bottle
Securely place Stopper into culture tube

August 16, 2014, at 03:47 PM by chris -

Changed line 44 from:

Fasten Luer lock connectors to tubing created in step 1

to:

Fasten a Male Luer lock connector to tubing created in step 1

Changed line 46 from:

Attach Teflon air filter to connecter side of tubing

to:

Attach the female end of the Teflon air filter to other end of the tubing

August 16, 2014, at 03:43 PM by chris -

Changed lines 17-18 from:

(2) 3" tube

to:

(1) 1" tube
(1) 3" tube

Changed line 20 from:

(1) 5' long tube

to:

(1) 5' tube

Added lines 22-26:

Attach two 6-way barb manifolds end-to-end with the 1" section of tube.
On the two other ends attach the 3" and 5' tubes.
On the remaining 8 ends of the barb manifolds attach the 8 2' tubes.
On the 8 2' pieces of tubing attach male Luer-barb connectors.
on the 2 remaining pieces, connect female Luer-barb connectors.

Changed line 42 from:

Cut tubing (2cm diameter?)

to:

Cut tubing (1/8" ID x 1/4" OD)

August 16, 2014, at 03:36 PM by chris -

Changed line 16 from:

Cut Tubing (50mm diameter?)

to:

Cut Tubing (1/16" ID 1/8" OD silicone). Note: you may adjust the length of tubing as needed for your configuration.

August 16, 2014, at 03:34 PM by chris -

Changed line 15 from:

If preparing for the first time, do steps 1-2 else skip to 3

to:

If preparing for the first time.

Added lines 22-26:

If reusing tubing.

Inspect the tubing.
1. Check the tubing for holes and leaks.
2. Check the tubing for fatigue cause by the pinch valves. Look for dents in the tubing, if it looks bad enough or tears when stretched, replace the tubing.

Changed lines 30-32 from:

Rinse with DI water

to:

Rinse with DI water.
1. Note: It's important to thoroughly rinse all tubing. Any left over media will burn in the autoclave and may discolor the media used to blank the system.

August 16, 2014, at 03:29 PM by chris -

Changed line 20 from:

Assemble tubes together in an "octopus" system

to:

Assemble tubing manifold

Changed line 22 from:

Rinse octopus tubing system

to:

Rinse tubing system

Added line 24:

using a squeeze bottle flush ethanol into each opening of the 10 way tubing manifold.

August 16, 2014, at 03:27 PM by chris -

Changed line 10 from:

Six Way Connector\\\

to:

Six Way Manifold\\\

August 14, 2014, at 09:06 PM by chris -

Deleted line 36:

NEED TO EXPLAIN HOW TO CREATE STOPPER WITH NEEDLES IN IT

August 14, 2014, at 09:04 PM by chris -

Changed line 67 from:

Set the temperature to 121 deg C?

to:

Set the temperature to 121 °C?
