intfil.f90 File Reference

Go to the source code of this file.

Functions/Subroutines
subroutine	intfil (val, mi, mj, time, flaguse, nrowst, ncolst, ilo, ihi, jlo, jhi, level, nvar, naux, msrc)
	Fill values for a patch at the specified level and location, using values from grids at level level ONLY! Leave cells that are not filled unchanged. More...
integer pure function	iadd (ivar, i, j)
integer pure function	iadnew (ivar, i, j)
integer pure function	iadold (ivar, i, j)

Function/Subroutine Documentation

integer pure function intfil::iadd	(	integer, intent(in)	ivar,
		integer, intent(in)	i,
		integer, intent(in)	j
	)

Definition at line 293 of file intfil.f90.

Referenced by basecheck(), bufnst2(), colate2(), conck(), drivesort(), iadd(), icall(), intcopy(), intfil(), preicall(), preintcopy(), update(), and valout().

Here is the caller graph for this function:

integer pure function intfil::iadnew	(	integer, intent(in)	ivar,
		integer, intent(in)	i,
		integer, intent(in)	j
	)

Definition at line 299 of file intfil.f90.

Referenced by intfil().

Here is the caller graph for this function:

integer pure function intfil::iadold	(	integer, intent(in)	ivar,
		integer, intent(in)	i,
		integer, intent(in)	j
	)

Definition at line 305 of file intfil.f90.

Referenced by intfil().

Here is the caller graph for this function:

subroutine intfil	(	real(kind=8), dimension(nvar,mi,mj), intent(inout)	val,
		integer, intent(in)	mi,
		integer, intent(in)	mj,
		real(kind=8), intent(in)	time,
		integer(kind=1), dimension(ilo:ihi, jlo:jhi), intent(inout)	flaguse,
		integer, intent(in)	nrowst,
		integer, intent(in)	ncolst,
		integer, intent(in)	ilo,
		integer, intent(in)	ihi,
		integer, intent(in)	jlo,
		integer, intent(in)	jhi,
		integer, intent(in)	level,
		integer, intent(in)	nvar,
		integer, intent(in)	naux,
		integer, intent(in)	msrc
	)

Fill values for a patch at the specified level and location, using values from grids at level level ONLY! Leave cells that are not filled unchanged.

Search the intersection of a grid patch with corners at ilo,ihi, jlo,jhi and all grids mptr on level level. If there is a non-null intersection, copy the solution and auxiliary values from grid mptr into val array.

Assume called in correct order of levels, so that when copying is ok to overwrite.

It uses array, flaguse, to indicate whether each cell is filled. All cells outside computational domain will be marked as "used" as well and will be processed later by bc2amr() in filrecur().

Input:

• a patch that needs to be filled
• global indices that describe the patch to be filled
• the grid msrc that might contain with the patch
• relative position of the patch to grid msrc (nrowst, ncolst)

Output:

• data array val that stores the new values
• flagging array, flaguse that indicates whether a cell is filled

Algorithm

If msrc , this patch is not associated with any grid. So the ''group of grids'', S, below contains all level level grids.

If msrc , this patch is contained in grid msrc. So the ''group of grids'', S, below only contains level level grids that intersect with grid msrc. Size of S is smaller in this case.

procedure intfil()
    for each grid mptr in a group of grids, S, do
        if grid mptr intersect with the patch
            if grid mptr has values at the time needed
                copy values inside the intersection from grid mptr to val
                mark cells in this intersection as "used"
            else
                interpolate from values on grid mptr at two different time
                fill the intersection with interpolated values
                mark cells in this intersection as "used"
            end if
        end if
    end for
    mark any portion of the patch that is out of whole computational domain as "used",
    which will be processed by bc2amr elsewhere later

Parameters

val	array where values are copied to. The array covers the whole grid msrc
mi	size of val array in i direction
mj	size of val array in j direction
time	simulation time of the values in val array
flaguse	marks indicating whether a position in val is filled
nrowst	local i index (relative to lower-left corner of grid msrc) of the left-most cell of the patch to be filled
ncolst	local j index (relative to lower-left corner of grid msrc) of the lower-most cell of the patch to be filled
ilo	global i index of left-most cell of the patch to be filled
ihi	global i index of right-most cell of the patch to be filled
jlo	global j index of lower-most cell of the patch to be filled
jhi	global j index of upper-most cell of the patch to be filled
level	This patch is on level level
nvar	number of equations for the system
naux	number of auxiliary variables
msrc	index of the grid that contains this patch

Definition at line 98 of file intfil.f90.

References iadd(), iadnew(), iadold(), and outtre().

Referenced by filrecur().

Here is the call graph for this function:

Here is the caller graph for this function:
